Tanque de almacenamiento de oxígeno médico O2 de doble capa para uso hospitalario
Especificaciones / funciones principales
N º de Modelo.: Hits: 0
Tanque de almacenamiento de oxígeno médico de doble capa Proveedor: tanque de almacenamiento de oxígeno médico O2, doble capa, aislamiento de fibra de vacío, aislamiento térmico, contenedores criogénicos.
Solicitar
Etiquetas:
Detalles
Debido a la rápida propagación de la COVID-19, el almacenamiento de oxígeno médico es especialmente importante. DFC está comprometida con el diseño y fabricación de recipientes a presión industriales, especialmente tanques de almacenamiento de oxígeno médico. Haremos todo lo posible para producir tanques de almacenamiento de alta calidad para contribuir a la lucha contra la epidemia.
Features of cryogenic storage tanks:
1. Vacuum powder insulation.
2. Vacuum fiber insulation.
3. Vacuum microsphere insulation.
4. Heat insulation.
5. Fiber (glass, ceramic, mineral, plant fiber, etc.).
6. Powder (expanded pearl sand, magnesium carbonate, diatomaceous earth, aerogel, etc.)
7. Foam (foamed polyurethane, expanded polystyrene, hair Foam glass, microporous rubber, etc.).
8. Light-blocking agents, aluminum foil, aluminized film, etc., which play a reflective role.
9. Low-temperature adsorbents such as activated carbon and molecular sieves play a role in vacuum low-temperature adsorption.
In terms of insulation effect, the current high vacuum multi-layer insulation effect is good, followed by vacuum powder or fiber insulation. As far as the scope of application is concerned, high-vacuum multi-layer insulation or vacuum fiber insulation is suitable for transport-type cryogenic containers, and vacuum powder insulation is suitable for fixed-type cryogenic containers. At present, a large number of products of this kind are manufactured and used in my country.
| TYPE | MODEL | LO2 STORAGE TANK SPECIFICATION | EMPTY WEIGHT （KG） |
|
| Inside shell (mm) | Outside Shell(mm) | |||
| Vertical | DFC5CBM/0.8 | φ1400X3672X6 | φ1900X5115X8 | 4160 |
| Vertical | DFC5 CBM /1.6 | φ1400X3672X8 | φ1900X5115X8 | 4650 |
| Vertical | DFC10 CBM /0.8 | φ1700X4705X6 | φ2200X6035X8 | 6035 |
| Vertical | DFC10 CBM /1.6 | φ1700X4705X10 | φ2200X6035X8 | 6850 |
| Vertical | DFC15 CBM /0.8 | φ1800X6214X6 | φ2300X7730X8 | 8196 |
| Vertical | DFC15 CBM /1.6 | φ1800X6214X11 | φ2300X7730X8 | 9780 |
| Vertical | DFC20 CBM /0.8 | φ2100X6146X7 | φ2600X7655X8 | 9715 |
| Vertical | DFC20 CBM /1.6 | φ2100X6146X12 | φ2600X7655X8 | 11450 |
| Vertical | DFC30 CBM /0.8 | Φ2100X9046X8 | Φ2600X10605X8 | 13270 |
| Vertical | DFC30 CBM /1.6 | Φ2100X9046X14 | Φ2600X10605X8 | 15790 |
| Vertical | DFC50 CBM /0.8 | Φ2600X9885X9 | Φ3200X11670X10 | 21725 |
| Vertical | DFC50 CBM /1.6 | Φ2600X9885X16 | Φ3200X11670X10 | 26500 |
| Vertical | DFC100 CBM /0.8 | Φ3000X14670X11 | Φ3600X16550X14 | 43386 |
| Vertical | DFC100 CBM /1.6 | Φ3000X14670X20 | Φ3600X16550X14 | 53300 |
| Vertical | DFC150 CBM /0.8 | Φ3200X19308X12 | Φ3800X22000X14 | 61500 |
| Vertical | DFC200 CBM /0.8 | Φ3400X22624X14 | Φ4000X25300X14 | 76800 |
| TYPE | MODEL | SPECIFICATION | EMPTY WEIGHT （KG） |
|
| Inside shell | Outside Shell | |||
| Horizontal | DFC5 CBM /0.8 | φ1400X3672X6 | φ1900X4802X8 | 3850 |
| Horizontal | DFC5 CBM /1.6 | φ1400X3672X8 | φ1900X4802X8 | 4550 |
| Horizontal | DFC10 CBM /0.8 | φ1700X4705X6 | φ2200X5980X8 | 5830 |
| Horizontal | DFC10 CBM /1.6 | φ1700X4705X10 | φ2200X7210X8 | 6750 |
| Horizontal | DFC15 CBM /0.8 | φ1900X5626X6 | φ2400X7210X8 | 8140 |
| Horizontal | DFC15 CBM /1.6 | φ1900X5626X11 | φ2400X7210X8 | 9680 |
| Horizontal | DFC20 CBM /0.8 | φ2100X6146X7 | φ2600X7310X8 | 9200 |
| Horizontal | DFC20 CBM /1.6 | φ2100X6146X12 | φ2600X7310X8 | 11000 |
| Horizontal | DFC30 CBM /0.8 | Φ2100X9046X8 | Φ2600X10200X8 | 13400 |
| Horizontal | DFC30 CBM /1.6 | Φ2100X9046X12 | Φ2600X10300X8 | 15800 |
| Horizontal | DFC50 CBM /0.8 | Φ2600X9885X8 | Φ3200X11400X10 | 21030 |
| Horizontal | DFC50 CBM /1.6 | Φ2600X9885X14 | Φ3200X11275X10 | 24800 |
| Horizontal | DFC100 CBM /0.8 | Φ3000X14670X10 | Φ3600X16350X12 | 41200 |
| Horizontal | DFC100 CBM /1.6 | Φ3000X14670X16 | Φ3600X16900X12 | 45920 |
| Horizontal | DFC150 CBM /0.8 | Φ3200X19308X10 | Φ3800X20700X12 | 55200 |
| Horizontal | DFC200 CBM /0.8 | Φ3400X22624X11 | Φ4000X24500X12 | 72400 |
Features of cryogenic storage tanks:
1. Vacuum powder insulation.
2. Vacuum fiber insulation.
3. Vacuum microsphere insulation.
4. Heat insulation.
5. Fiber (glass, ceramic, mineral, plant fiber, etc.).
6. Powder (expanded pearl sand, magnesium carbonate, diatomaceous earth, aerogel, etc.)
7. Foam (foamed polyurethane, expanded polystyrene, hair Foam glass, microporous rubber, etc.).
8. Light-blocking agents, aluminum foil, aluminized film, etc., which play a reflective role.
9. Low-temperature adsorbents such as activated carbon and molecular sieves play a role in vacuum low-temperature adsorption.
In terms of insulation effect, the current high vacuum multi-layer insulation effect is good, followed by vacuum powder or fiber insulation. As far as the scope of application is concerned, high-vacuum multi-layer insulation or vacuum fiber insulation is suitable for transport-type cryogenic containers, and vacuum powder insulation is suitable for fixed-type cryogenic containers. At present, a large number of products of this kind are manufactured and used in my country.
